ISDP Intrinsically Safe Differential Pressure Transmitter

Name: ISDP Intrinsically Safe Differential Pressure Transmitter
SKU: placeholder-isdp-intrinsically-safe-differential-pressure-transmitter
Price: 1412.20 USD
Availability: InStock

4 - 20 mA process output, a robust NEMA 4X enclosure, large LCD display, & password protected set up menu

Starting at

$1,412.20USD

Have questions? We're here to help!

Call

Configure

Used in

Also found in

ISDP Intrinsically Safe Differential Pressure Transmitter 02389

The Series ISDP Differential Pressure Transmitter provides a 4 - 20 mA process output, a robust NEMA 4X enclosure, plus a large LCD display that can be programmed to read in pressure, velocity or flow. The ISDP offers simplified programming via a Menu key that enables the user to select: security level; English or Metric engineering units; pressure, velocity or flow operation, K-factor for use with various Pitot tubes and flow sensors, circular or rectangular duct size for volumetric flow operation plus many more. The Series ISDP Differential Pressure Transmitter is powered on its two wire loop with 10-35 VDC via its integral M-12 four pin male connector. The ISDP provides a 0.5% full scale accuracy on ranges from 0.25 in W.C. - 100 in W.C. as well as bi-directional models up to 10 in W.C. These features make the Series ISDP Differential Pressure Transmitter the ideal instrument for monitoring pressures or air flows in hazardous zones having a Class I Div. I Groups A, B, C, D; Class II Div. I Groups E, F, G; Class III Div. I ratings.

• NEMA 4X rated enclosure provides protection in harsh environments permitting outdoor monitoring or in areas where dust and particulate matter exists
• Easy to read LCD display provides immediate local alerts allowing corrective action to be taken quicker to eliminate the problem from becoming widespread
• Intrinsically safe for use in the specified hazardous locations meets specifications where pressure transmission and safety cannot be compromised
• Password protected set up menu helps to insure no errors by untrained personnel when accessing the powerful measurement capabilities of this device

Service	Air and non-corrosive gases
Wetted Materials	Ranges 5 in W.C. and greater: glass, PVC, silicon, alumina ceramic, epoxy, RTV, gold, aluminum, stainless steel and nickel; Ranges 1 in W.C. and less: stainless steel, silicone, gold, ceramic
Housing Materials	Aluminum, glass
Accuracy	± 0.5% at 77°F (25°C) including hysteresis and repeatability (after 1 hr warm-up)
Stability	< ± 1% per year
Pressure Limits	Ranges ≤ 2.5 in W.C.: 2 PSI; 5 in W.C.: 5 PSI; 10 in W.C.: 5 PSI; 25 in W.C.: 5 PSI; 50 in W.C.: 5 PSI; 100 in W.C.: 9 PSI
Temperature Limits	32°F - 140°F (0°C - 60°C)
Compensated Temperature Limits	32°F - 140°F (0°C - 60°C)
Thermal Effects	0.020%/°F (0.036/°C) from 77°F (25°C)
Power Requirements	10 VDC - 35 VDC
Output Signal	4 - 20 mA DC
Zero & Span Adjustments	Accessible via menus
Response Time	250 ms (damping set to 1)
Display	4 digit LCD 0.6 in height
Electrical Connections	M-12 4 PIN Connector
Process Connections	1/8 in female NPT
Enclosure Rating	Designed to meet NEMA 4X (IP66)
Mounting Orientation	Mount unit in vertical plane
Weight	2 lb 10 oz (1.19 kg)
Agency Approvals	CE: CENELEC EN 61326/55024: 2003; IEC 61000-4-2/3/4/6: 2001/2006/2004/2005; CENELEC EN 55011: 2006; 2004/108/EC EMC Directive; FM Intrinsically Safe CLI Div I GR: A, B, C, D; CLII Div I GR: E, F, G; CLIII Div I
