T5-600 / 62 MAX+ / 1AC II IR Thermometer, Electrical Tester and Voltage Detector Kit

Name: T5-600 / 62 MAX+ / 1AC II IR Thermometer, Electrical Tester and Voltage Detector Kit
SKU: placeholder-t5-600-62-max-1ac-ii-ir-thermometer-electrical-tester-and-voltage-detector-kit
Price: 391.99 USD
Availability: InStock

Solve problems quicker by first testing for overheated electrical devices using an IR thermometer

Have questions? We're here to help!

Call

Used in

Also found in

T5 600 62 MAX 1 AC II IR Thermometer Electrical Tester and Voltage Detector Kit 03269

This kit is designed to help electricians and HVAC technicians solve problems quicker. Test first for overheated electrical devices using an IR thermometer; then use electrical test tools to find out more about the problem.

Kit includes the Fluke T5-600 Electrical Tester and the Fluke 62 MAX+ Infrared Thermometer.

Fluke T5 Voltage, Continuity and Current Testers:
• Automatically measures volts AC and volts DC with precise digital resolution
• Displays resistance to 1000 Ω
• Easy and accurate OpenJaw™ current measurement
• Continuity beeper
• Rugged enough to withstand a 10 ft (3 m) drop
• 600 V model
• Auto off mode to conserve battery life
• AC current
• Display hold
• All inputs of the T5-600 are protected to EN61010-1 CAT III 600V. UL, CSA and VDE listed

Fluke 62 MAX+:
• Dust and water-resistant: IP54 rated
• Rugged: 3 m (9.8 ft) drop tested
• Ergonomically designed: Completely redesigned for a more natural hand fit
• Distance to spot: 12:1
• Dual lasers: Identifies area to be measured
• Large, backlit display: Makes data easier to read, even in dark areas
• C115 Deluxe soft carrying case with shoulder strap

Fluke T5-600 Voltage, Continuity and Current Tester

Specifications
Jaw Opening	12.9 mm (0.5 in)
Max. Wire Size	1/0 THHN Cable
Current Range AC RMS	0 A - 100.0 A
Accuracy AC Current (50 Hz / 60 Hz)	3 % +/- 3 counts
AC Response	Averaging
Voltage Range AC	0 V - 600 V
Accuracy AC Voltage	1.5 % +/- 2 counts
Voltage Range DC	0 to 600 V
Accuracy DC Voltage	1 % +/- 1 count
Resistance Range	0 Ω - 1000 Ω
Continuity Beeper Threshold	On at < 25 Ω, off at > 400 Ω
Volts Indicator LED Threshold	Guaranteed on by 30 V AC
