SP-002-1 Smart IR Sensor

Name: SP-002-1 Smart IR Sensor
SKU: placeholder-sp-002-1-smart-ir-sensor
Availability: InStock

Smart IR Sensor -70°C to 380°C Temperature

Have questions? We're here to help!

Call

Used in

The Omega Smart IR Temperature Probe is a miniature infrared sensor that measures the surface temperature of a solid or liquid without contact. It can measure non- metal surfaces between -70 to 380°C (-94 to 716°F). It also features a built-in sensor to measure the ambient temperature of the probe itself. Materials including paper, thick plastics, rubber, food and organic materials, as well as painted metals and most dirty, rusty or oily surfaces, are measured accurately, safely and cleanly.

The Smart Probe is packaged into a rugged 12 mm OD x 67 mm long compact, stainless steel, IP67 (NEMA 6) housing - designed for heavy industrial use while taking up the least amount of space for easy installation. Standard features include: easy configuration through free SYNC configuration software, adjustable emissivity and filtering, and a wide operating temperature range of -40°C to 85°C.

We’ve integrated an advanced suite of IIoT centric electronics called Smart Core. These features enable plug and play connectivity, fully featured alarms and notifications, data assurance, and data storage of up to 1499 sensor readings.

The Smart Probes’s OEG support makes it ideal for asset monitoring and predictive maintenance applications. It can be connected to a PC or server where OEG (Omega Enterprise Gateway) software can reside for data display, long-term data logging, alarming, and analytics. OEG is available without OPC UA/DA as a Standard free version. See all the features of OEG.

• Fully Integrated Microprocessor based Smart Digital Sensor solution

• 10:1 FOV

• Discrete I/O configurable for alarms, switch inputs and control signals

• Measures both ambient and surface temperature

Temperature Range	-70 to +380°C (-94 to 716°F)
Accuracy @ Ambient of 0-50°C (32 to 122°F):	1°C (1.8°F) or 1% of reading, whichever is greater
Accuracy Over Entire Ambient Operating Range	4°C (3.6 °F) or 3% of reading, whichever is greater
Repeatability	1°C (1.8°F) or 1% of reading
Emissivity	0.01 to 1.00, software adjustable
Response Time	30 to 1500 msec, adjustable
Spectral Response	5.5 to 14 microns
Supply Power	3.3 Vdc, 0.05 W max
Field of View	SP-001 is 6:1 SP-002 is 10:1
Mechanical
Construction	Stainless Steel
Thread Mounting Dimensions	12 OD x 114 mm L (0.47" x 4.49")
Weight	35 g (1.2 oz)
Environmental
Environmental Rating	NEMA 6, IP67
Acceleration Test	10 g (10 to 500Hz)
Operating Temperature	-40 to 85°C (-40 to 185°F) less than 95% RH, non-condensing
General
Agency Approvals	CE, EMC 2014/30/EU, LVD 2014/35/EU
Configuration	Configurable via IF-001 and Sync configuration software
Software	Compatible with OEG and Sync configuration software
