Seek Thermal

Seek Scan Thermal Imaging System

Simple, low-cost, thermal imaging system designed to automate body temperature screening using skin temperature as a proxy, ±0.3°C (±0.5°F) accuracy

Starting at
$2,115.38USD
Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Configure
Used in
Seek Scan Thermal Imaging System 07013
Seek Scan 2
Seek Scan 3
Seek Scan 4

Seek Scan is a simple, low-cost, thermal imaging system designed to automate body temperature screening using skin temperature as a proxy. With ±0.3°C (±0.5°F) accuracy and the inclusion of a reference heat source, Seek Scan delivers the same performance as an infrared temporal thermometer – but automated from a safe social distance.

The system can be installed in lobbies, hallways and other key access points to help businesses, institutions and venues reopen a safer environment for their workforce, customers, members and patrons. Easy-to-install and easy-to-use, the system can be up and running in minutes with no special equipment or training.  Additionally, Seek Scan can be integrated with access control and video management systems using our APIs available to integrators.

• Fast, automated screening
  - In seconds, the system detects a face, finds the most reliable spot to measure and displays a pass/fail alert.
• Meets FDA guidelines
  - Seek Scan meets the accuracy specification, includes a reference heat source and is made for single person screening.
• Enables social distancing
  - Delivers the same performance as a temporal thermometer – but with a safe social distance
• Email Notifications
  - Receive an email notification every time someone measures above the customizable alarm temperature.
• API Integration
  - Send alarm events, stream, trigger access control and VMS,  and pull data to integrate multiple Seek Scans into one enterprise solution.
• Affordable
  - Affordable thermal screening system that meets FDA guidelines for initial body temperature assessment during the Covid-19 Public Health Emergency

Camera Specifications
Thermal Sensor Resolution206 (h) x 156 (v)
Visible Light Camera Resolution640 x 480
Horizontal / Vertical Field of View35° (h) / 26° (v)
Lens Focal Length / F-Number4.0mm / f/1.20
Frame Rate<9Hz
PowerUSB 5V (Plugs into Computer USB-A port)
Dimensions (L x W x H) & Weight3 x 8 x 9 cm / 140 g
Tripod Mount1/4"-20 Standard Camera Tripod Mount
Fixed Heat Source Specifications
Temperature-Controlled DeviceEmits a constant reference temperature
Power110V to 220V 50/60Hz (Plugs into Wall Outlet)
Dimensions (L x W x H) & Weight3 x 9 x 9.5 cm / 80 g
Tripod Mount1/4"-20 Standard Camera Tripod Mount
Measurement Specifictions
Temperature Accuracy± 0.3°C (0.5°F) typical between 36°C to 40°C (96°F to 104°F)
@ 1.5 meters (5 feet) Verified in a laboratory setting using a fixed heat source
Sensor Sensitivity40 mK typical, <50 mK max @ 25°C (Post Signal Processing)
System Specifications
Scan Measurement Time1 to 3 seconds typical
Operating TemperatureOptimal temperature accuracy in conditions below 105°F (40°C) ambient
API CapabilitiesRTSP streaming video and UDP & TCP commands via JSON
PC/Tablet Requirements
OS RequirementsWindows 10 64-bit OS Home/Pro
Processor Requirements1.2 GHz processor
RAM Requirements4 GB
Hard Drive Requirements+10 GB
