 Maximum Control, Miniature Size

For PLC systems that require weight data from a scale, Rice Lake’s compact SCT-10 transmitter delivers equivalent signal-conditioning function without the cost or bulk of a full-size weight indicator/controller.

Rice Lake's SCT-10 is DIN-rail mountable within a cabinet or control panel, where they convert a scale’s load cell signal to serial or analog output. Technicians and operators find the analog output signal particularly useful for monitoring hopper filling and discharge. Unlike many other signal transmitters, Rice Lake SCTs have their own integrated display, with annunciators for unit and weighing status, and push buttons or toggle switch and digital rotary for zero, tare and setpoint entry—ultimately simplifying scale setup, calibration and operation.

• Converts digital weight to analog output
• Sums four input channels in parallel
• Theoretical calibration, real-weigh calibration, linearity calibration
• Push-button or preset tare
• Full-scale analog output with zero setting and PLC correction of analog signal
• Displays weight, configuration, calibration and error conditions
• DIN-rail mounting, suitable for back panel
• Two digital inputs, two digital outputs
• Supports ASCII or MODBUS-RTU protocols
Temperature & HumidityOperating Temperature: -4 °F to 140 °F (-20 °C to 60 °C)
Humidity: 85% non-condensing
Rating/MaterialDIN rail mount: NEMA Type 1
Enclosure: NEMA Type 4/IP67, plastic
Clear cover: six PG9 cord grips
Weight1 lb (0.5 kg)
WarrantyOne-year limited
ApprovalscULus Recognized
PowerInput: 12 to 24 VDC
Power consumption5 W
Excitation Voltage5VDC, 120mA, 8 × 350 ohm load cells
Analog Signal Input Range+/- 19.5 mV
Analog Signal Sensitivity0.3 μV/graduation minimum
1.0 μV/graduation recommended
A/D Sample Rate80 Hz
ResolutionInternal: 16,000,000 counts
Display: 999,999
System Linearity± 0.01% full scale
Digital I/O2 inputs 5-24VDC, 2 outputs
24 VDC/60 mA
N.O. or N.C. (solid state)
Communication PortsRS-485 or RS-232 simplex supports up to 115,200 bps
Analog OutputOptoisolated, 16 bit
0-20 mA, 4-20 mA (max 300 ohm)
0-10 VDC, 0-5 VDC, -10 to 10 VDC, 5 to 5 VDC, (min 10 k ohm)
AnnunciatorsNet, center of zero, stability, KG, G, LB
Display0.3 in (8 mm), six-digit, 7 segment LED
Keys/Buttons4-key membrane panel, tactile feel
Zero, Tare, Print, Menu, Escape,
Left and Up Navigation, Enter
Dimensions(L × W × H)
DIN Rail Mount: 4.84 × 3.62 × 1.96 in (123 × 92 × 50 mm)
Enclosure: 6.69 × 5.51 × 3.74 in (170 × 140 × 95 mm)
