Dwyer

RHPLC Wall Mount Humidity/Temperature Transmitter

Compact economical sensor for the building automation market space

Starting at
$130.90USD
Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Configure
Used in
RHPLC Wall Mount Humidity Temperature Transmitter 07301
RHPLC Wall Mount Humidity Temperature Transmitter bd8c9

 The Series RHPLC Wall Mount Humidity/Temperature Transmitter is a compact economical sensor for the building automation market space. The stylish housing is well vented to provide air flow across the sensor to improve measurement accuracy. Each unit utilizes a capacitive polymer sensing element to deliver a proportional analog output. A combination humidity and temperature model can be configured with current, voltage, RTD, or thermistor output. A wide selection of passive RTD or thermistor temperature sensors are available in this series.

• 2% or 3% accuracy models
• Humidity only or temperature and humidity combo
• Wide selection of passive thermistor or RTD temperature sensors
Agency Approvals:CE.
Weight:4.4 oz (125 g).
Enclosure Material:Polycarbonate.
Drift:<0.25% RH/year.
Electrical Connections:Screw terminal block.
Response Time:8 s (π63).
Power Requirements:10 to 35 VDC for 4 to 20 mA or 0 to 5 VDC output; 15 to 35 VDC for 0 to 10 VDC output; 10 to 29 VAC for 0 to 5 VDC output; 15 to 29 VAC for 0 to 10 VDC output.
Temperature Limits:Operating: -40 to 140°F (-40 to 60°C); Storage: -40 to 176°F (-40 to 80°C).
Accuracy Current/Volt Temp Output:±0.9°F @ 72°F (±0.3°C @ 25°C).
Accuracy RTD Temp Sensor:DIN Class B; ±0.3°C @ 0°C (±0.54°F @ 77°F).
Passive Thermistor Temp Sensor Accuracy:±0.36ºF @ 77°F (±0.2°C @ 25°C).
Temperature Output Range:-40 to 140°F (-40 to 60°C).
RH Repeatability:±0.1% typical.
RH Hysteresis:±0.8%.
RH Accuracy:±2% 10 to 90% RH @ 25°C for 2% accuracy units; ±3% 20 to 80% RH @ 25°C for 3% accuracy units.
Relative Humidity Range:0-100% RH.
Sensor:Capacitive polymer.
• Air economizers
• Room comfort monitoring
