pHTemp2000 Data Logger

Name: pHTemp2000 Data Logger
SKU: placeholder-phtemp2000-data-logger
Price: 669.00 USD
Availability: InStock

Battery powered pH & Temp. data logger w/ an LCD, up to 131,071 readings per channel, automatic temperature compensation

Buy now!

$669.00USD

Have questions? We're here to help!

Call

QTY

Used in

The pHTemp2000 is a pH and temperature data logger with an LCD and wall mounted universal power adapter.

The pHTemp2000 accepts 2, 3 and 4-wire RTDs and can store up to to 131,072 readings. To maximize memory capacity, users can enable or disable channels. This device directly connects to many commonly used pH and ORP electrodes through a female BNC connector mounted on its side. Temperature is measured by directly connecting an RTD to the pHTemp2000.

The pHTemp2000 is compatible with the latest MadgeTech 4 Software making starting, stopping, and downloading simple and easy. Graphical, tabular, and summary data is provided for analysis and can be viewed as customizable engineering units.

• Large LCD display
• User-friendly
• Automatic temperature compensation
• Programmable start time
• Real time operation
• Programmable engineering units

Material	Black anodized aluminum
Dimensions	4.8 in x 3.3 in x 1.25 in (122 mm x 84 mm x 32 mm)
Operating Environment	-5 °C to +50 °C (+23 °F to +122 °F), 0 %RH to 95 %RH non-condensing
Required Interface Package	IFC200
Approvals	CE
Temperature Sensor	2, 3 or 4 wire 100 Ω Platinum RTD
Temperature Resolution	0.01 °C (0.018 °F)
Temperature Calibrated Accuracy	±0.15 °C
Probe Temperature Range	-40 °C to +110 °C (-40 °F to +230 °F)
pH Range	-2 pH to +16 pH (±1000 mV)
pH Resolution	0.01 pH/0.001 pH
pH Accuracy	±0.01 pH
Memory	131,071/channel
Reading Rate	1 reading every 2 seconds up to 1 reading every 24 hours
Baud Rate	115,200
Battery Life	1 year battery life at one minute reading rate with display off. 30 days typical with continuous display use. Optional AC adapter available.

Temperature
Temperature Sensor	2, 3 or 4 wire 100 Ω Platinum RTD
Temperature Resolution	0.01 °C (0.018 °F)
Temperature Calibrated Accuracy	± 0.15°C
Probe Temperature Range	- 40°C - 110°C (-40°F - 230°F) (80 Ω - 145 Ω)
Input Connection	Removable Screw Terminal; 2, 3, or 4-wire interface
pH / ORP / ISE
Input Connection	Female BNC
Measurement Range	-2 pH - 16 pH (± 1000 mV)
Resolution	0.01 pH / 0.001 pH
pH Accuracy	± 0.01 pH
pH EMI Susceptibility	< 0.2 pH @ 3 V/M, 80 MHz - 1 GHz
ORP / ISE Accuracy	± 0.1 mV
ORP / ISE EMI Susceptibility	< 10 mV @ 3 V/M, 80 MHz - 1 GHz

• Surface and ground water quality monitoring
• Environmental and wetlands monitoring
• Industrial influent and effluent
• Water districts and municipal water systems
• Process water quality
• Recreation and park management
• Pulp and paper industry
• Wastewater monitoring
