M202 Absolute Manometer

Name: M202 Absolute Manometer
SKU: placeholder-m202-absolute-manometer
Price: 3745.00 USD
Availability: InStock

Precision absolute manometer brings calibration bench accuracy to a portable, handheld unit

This product is no longer available. Contact us at 800-567-8686 for alternative solutions.

Have questions? We're here to help!

Call

Meriam’s model M202 Precision Absolute Manometer brings calibration bench accuracy to a portable, handheld unit. The pressure sensor is all 316 stainless steel, allowing it to be used with liquids, gases, and corrosives that are compatible with 316 stainless steel. This combination of accuracy and fluid compatibility makes the M202 ideal for environmental, test or real-time process measurements of pressure relative to absolute zero.

The M202 includes features for minimum and maximum (Min/Max) value capture, tare readings, and user selectable engineering units. A selectable altitude function allows users to enter site altitude above sea level in order to display local barometric pressure or barometric pressure corrected to sea level. User referenced altitude (referenced to map or trig markers) or altitude based on US Standard Atmosphere of 1962 can be selected for display. Using the altitude function with the Min/Max and Tare features makes the M202 very useful as a surveyor’s tool to accurately measure changes in altitude.

This product is an updated version of the 355.

• Impressive accuracy
• Numerous applications including leak testing and pressure drop monitoring
• Compatible with a wide variety of materials including liquids, gases, and corrosives (that are compatible with 316 stainless steel)
• Contrast adjustment for best viewing
• User enabled automatic shut-off to save battery life
• Recalibrate in the field
• Designed to handle tough applications

Accuracy	AI0017: FS = 17.403 PSIA or 900 mm Hg abs. ± 0.02% F.S. AI0038: FS = 38.674 PSIA or 2,000 mm Hg abs., ± 0.015% F.S. from 0 - 19.337 PSIA (0 - 1,000 mm HgA) ± 0.025% F.S. from 19.338 - 38.674 PSIA (0 - 1,000 - 2,000 mm Hg abs.)
Display	5 significant digit LCD (0.25 in high) 2 line x 16 alphanumeric characters
Power	Four (4) AA alkaline batteries with user enabled automatic shut-off
Process Connections	1⁄8 in female NPT, 316 stainless steel
Media Compatibility	Isolated AI sensor for fluids compatible with 316 stainless steel
Pressure Limits	77 PSIA (4,000 mm Hg)
Engineering Unit Selection	mm Hg, PSI, in Hg, mbar, bar, kPa, Torr, ft, m
Storage Temperature	-40°C - 60°C (-40°F - 140°F)
Operating Temperature	-5°C - 50°C (23°F - 122°F)
N.I.S.T. Traceability	N.I.S.T. certificate supplied for all models
Materials	ABS plastic case
Weight	14 oz
Dimensions	6.5 in x 3.6 in x 2.25 in)
Other Features	Backlight, contrast adjustment, field recalibration, tare
Approvals	CE compliant, Intrinsically Safe (cULus and ATEX)
