IN-UVI Wheatstone Bridge In-Line Amplifier w/ Field Selectable I/O

Wheatstone Bridge In-Line Amplifier

Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Used in
IN UVI Wheatstone Bridge In Line Amplifier w Field Selectable IO 12929

 The OMEGA IN-UVI in-line signal conditioner is housed in a rugged stainless steel enclosure, which is connected between the transducer and a readout instrument. The signal conditioner supplies a highly regulated bridge excitation voltage for the transducer and converts the millivolt signal of the transducer to 0 to 5, 0 to 10, ±5, ±10 Vdc or 4 to 20, 12 ± 8 mA.


The IN-UVI features include two selectable excitation voltages, programmable gain amplifier for signals from 0.5 mV/V to 4 mV/V, wide zero adjustment range and an isolated shunt calibration relay for quick field setup. All output options and excitation voltages are field selectable.

Ready-Made Cable Assemblies are now available to connect the IN-UVI to mV/V output sensors and to the power supply and display (see Specs for details).

• Wide Range of Field Selectable Inputs and Outputs
• Ready-Made Cable Assemblies for Transducer Connection Now Available!
• Input/Output Isolation
• Low Thermal Drift
Environmental ProtectionIP65
Shunt CalYes; remotely activated
Sensor Input Range0.5 mV/V to 4 mV/V in 0.5 steps
Excitation Max Current30 mA @ 10 Vdc
Excitation Voltage5 or 10 field programmable
Response Time200 uS (0 to 63%)
Operating Temperature-20 to 60°C (0 to 140°F)
Maximum Load Resistance700 Ω at 20 mA
Current Output4 to 20 mA, 12 mA zero ±8 mA outputs field programmable
Short Circuit ProtectionYes +output to -output
Noise10 mV peak to peak @ 3 mV/V voltage mode (10 Vdc) 20 uA peak to peak current mode
Output Resistance60 Ω
Voltage Output±5 volts, ±10 volts at 2 mA maximum
Input Current90 mA maximum (must be capable of supplying 200 mA)
Resistance100 MΩ
Capacitance0.022 µF
Isolation Input to Output500 Vdc
Time constant 0 to 63% (200 µS for a 350 Ω bridges/1.2 mS for a 5000 O bridge)
Bridge Resistance350 to 5000 Ω*
Bridge Sensitivity1 to 8 mV/V @ 5 Vdc EXC, 0.5 to 4 mV/V for 10 Vdc EXC
Bridge Excitation5 Vdc or 10 Vdc
Transducer Requirements
Dimensions134.8 L x 34.8 H x 31.2 mm D (5.3 x 1.37 x 1.23)
EMC Affect<0.1% per en 61326-1 (industrial)
Adjustment LocationBehind connector endcaps
Span±20% fine ±40% coarse
Zero±30%
Adjustment Range
Linearity0.01%
Span0.0025%/°F
Zero0.001%/°F (Auto zero front end)
Temperature Affects
Long Term Zero Drift0.1%/year
Supply Voltage22 to 32 Vdc isolated from output

 • Use with Miniature Load Cells

• Extent the range of mV/V Pressure Transducers
• Wheatstone Bridge Transducers
