HHT41B Handheld Digital Stroboscope w/Rechargeable Batteries

1 Rechargeable Battery Pack

Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Used in
HHT41 B Handheld Digital Stroboscope w Rechargeable Batteries 14096

 OMEGA's HHT41B set the industrial standard for high-intensity, multifunction, ultra-compact, xenon stroboscopes. It features a removable, rechargeable battery pack. Stop-action and slowmotion inspections are made easy with the one-touch, joystick-type tuning button. Additional features include rapid x2 and ÷2 of current flash rate, tachometer mode with external trigger, and memory recall functions. The HHT41B can even be operated "hands-free" with our standard tripod mounting bushing.


• Removable, Rechargeable Battery Pack 100 to 230 Vac
• One-Handed Operation
• Lightweight, Pocket Size
• Flash Rates to 12,500 FPM
Display6-digit alphanumeric backlit LCD, 7.6 mm (0.3") digits
Light Power150 mJ/flash, 1100 LUX as bright as 10 W units
Flash Duration10 to 30 µs typical
BatteryRechargeable battery pack (included) Nickel-Metal Hydride
Recharge CycleFully recharges in 4 to 5 hours
Run Time100 minutes typical at 1800 fpm with fully charged batteries
Adjustment4-quadrant, pressure-sensitive joystick button adjusts flash rate, x2 and ÷2
PowerRemovable 6V rechargeable battery pack with integral charge control electronics, included with all units
Weight0.63 kg (1.4 lb), including battery
Internal Mode
Flash Range100 to 12,500 fpm
Resolution0.1 FPM
Accuracy±0.5 FPM or ±0.01% of reading
Update RateInstantaneous
External Mode
Range and Display5 to 12,500 fpm
Update Rate1 second typical
fpm Accuracy±0.1 fpm or ±0.01 of reading
Trigger-to-Flash Delays< 5 µs
External Input0 to 5V, 5 TTL compatible (+12 Vp max), 20 ìs min pulse width; positive edge triggered
Tachometer Mode
Range5 to 250,000 rpm
Accuracy± 0.01% or 0.1 rpm
Update Rate1 second typical
External Input0 to 5V TTL compatible (+12 Vp max) 20 ìs min pulse width; positive edge triggered
