FPM-5750 Battery powered Flow Indicator an Totalizer

Name: FPM-5750 Battery powered Flow Indicator an Totalizer
SKU: placeholder-fpm-5750-battery-powered-flow-indicator-an-totalizer
Availability: InStock

Battery powered Flow Indicator and Totalizer

Have questions? We're here to help!

Call

Used in

FPM 5750 Battery powered Flow Indicator an Totalizer 13617

The FPM-5750 Battery Operated Flow Indicator and Totalizer is compatible with the following flowsensors: FP-5300, FP-5100, FP-5200 and FP-6000 flow sensors (see related links below). The large digital display indicates flow rate and totalized flow volume simultaneously. One of the threetotalizers is resettable from the front panel or a remote location, while the second resettable totalizer can only be reset by entering a user-selectable security code. Meanwhile, the third is a permanent non-resettable totalizer. Our intuitive software design and four button keypad provide for simple operation while setting screen displays and programming the system. Calibration can be easily performed by entering the Auto-Cal feature and entering a value to match an external reference. Screen displays can be modified to suit the user’s needs along with the flow rate, any of the three totalizers can be selected as the displayed totalizer. Users can quickly scroll through the totalizers simply by pressing any key on the keypad. A display averaging feature is included for applications wherethe flow in the pipe fluctuates. For applications where flow stops and starts due to production needs, ano-flow indicator will display the hours of non-flow.

This product is very similar to the FP90 Series transmitter and requires flow sensors and fittings to be purchased separately.

• Three Totalizers

• Long-lasting Lithium Batteries (Included)

• Mounting Versatility

• No-Flow Indicator

Input Freq. Range	0 to 400 Hz (sinewave)
Accuracy	±0.5% of reading
Display	LCD type
4-Digit Upper Line	Flow rate
8-Digit Lower Line	Volume totalizer count, resettable and permanent
Averaging	0 to 120 seconds
Contrast	Automatic
Low Battery Indication	Battery symbol appears on LCD display
8-Digit Resettable Totalizers Stored Unit User Resets	Continues to be stored even after batteries are removed
8-Digit Permanent	Kept permanently, even when batteries are removed
Enclosure	PBT resin
Keypad Material	Sealed 4-key silicon rubber
Panel Case Gasket	Neoprene®
Window	Polyurethane coated polycarbonate
Battery	Two "AA" 3.6V Lithium thionyl chloride (included)
Battery Life	4 years nominal ≤50°C (122°F)
Enclosure Rating	NEMA 4X (IP65) front
Operating Temperature	-10 to 65°C (14 to 149°F)
Storage Temperature	-40 to 100°C (-40 to 212°F)
Relative Humidity	0 to 95% non-condensing
Shipping Weight	0.5 kg (1.1 lb)
Dimensions	For panel version, cutout must be 92 x 92 mm2 (3.62 x 3.62")
Compatible Sensors	FP-5300/5100, FP-5200, and FP-6000, and FP-5600 (see related links below)
