E59-M30C129C02-D1 Cutler-Hammer 2-wire AC & 3-wire DC Inductive Proximity Senors

2-wire AC and 3-wire DC Inductive Proximity Sensors

Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Used in
E59 M30 C129 C02 D1 Cutler Hammer 2 wire AC 3 wire DC Inductive Proximity Senors 13969

 The Cutler-Hammer® iProx Series represents the highest performance, most versatile tubular inductive sensor offered by Omega. By utilizing an embedded microprocessor and exclusive SmartSense™ technology, iProx can sense up to three times farther than typical sensors of its class. Both shielded and unshielded versions of iProx feature extended sensing ranges. This allows the sensor to be mounted farther from the target, thereby reducing the potential for target impacts and increasing the sensing reliability of your application. With extended sensing range, quality construction and very high noise immunity, iProx is the ideal choice for even the most demanding inductive sensing applications.

• Available in AC 2-Wire, DC 3-Wire
• Up To 29mm Sensing Range
• Designed for High Temperature, High Pressure Washdown
• Ideal for Intense Shock and Vibration Applications
2-Wire Sensors
Input Voltage20 to 132 Vac
Load Current12 mm: 5 to 300 mA; 200 mA >50°C
Leakage Current≤1.7 mA @ 0°C, 2.0 mA @ -40°C
Voltage Drop<5 Vac
ProtectionNone
Switching Hysteresis<15% rated sensing distance
Repeat Accuracy
Shielded Models<1% sensing distance
Unshielded Models<3% sensing distance
Surge Capacity3A/30 ms
Temperature Range-40 to 70°C (-40 to 158°F)
Material of Construction303 SS; End bells: Polycarbonate; Face caps: Ryton®; Cable: AWM Style 20387 (PVC)
Vibration and Shock Vibration10 to 55 Hz, 1 mm Amplitude, IEC 60068-2-6; Shock: 30g, 11 mS per IEC 68-2-27
Indicator LED360° viewable LED
Enclosure RatingsNEMA 4, 4X, 6, 6P, 12 and 13 (IP67)
Response Time 2-Wire Sensors
Factory Default ModeShipped in 'side by side mode' by default (20 V/m)
Side by Side30 Hz (10 V/m)
High Noise Immunity Mode10 Hz (>20 V/m)
3-Wire Sensors
Input Voltage6 to 48 Vdc
Load Current≤500 mA @ 6 to 30 Vdc; ≤300 mA @ 32 to 48 Vdc Leakage Current: ≤150 µA Voltage Drop:≤2.5 Vdc Burden Current: ≤15 mA
ProtectionAuto Reset
Switching Hysteresis<15% rated sensing distance
Repeat Accuracy
Shielded Models<1% sensing distance
Unshielded Models< 3% sensing distance
Temperature Range-40 to 70°C(-40 to 158°F)
Material of Construction303 SS;
End bellsPolycarbonate; Face caps: Ryton®; Cable: AWM Style 20387 (PVC)
Vibration and Shock Vibration10 to 55Hz, 1 mm Amplitude, IEC 60068-2-6; Shock: 30g, 11 mS per IEC 68-2-27
Indicator LED360° viewable LED
Enclosure RatingsNEMA 4, 4X, 6, 6P, 12 and 13 (IP67)
Response Time 3-Wire Sensors
Factory Default Mode
Shielded
12 mm580 Hz (10 V/m)
18 mm390 Hz (10 V/m)
30 mm240 Hz (10 V/m)
Unshielded
12 mm:300 Hz (10 V/m)
18 mm150 Hz (10 V/m)
30 mm145 Hz (10 V/m)
Side by Side50 Hz (20 V/m)
High Noise Immunity Mode10 Hz (>20 V/m)
