DVP-120 Detection Ventilation Control Panels

Name: DVP-120 Detection Ventilation Control Panels
SKU: placeholder-dvp-120-detection-ventilation-control-panels
Price: 1737.07 USD
Availability: InStock

Designed to meet specifications for safety in enclosed parking garages, including the uniform building code & OSHA 50ppm CO requirements

Starting at

$1,737.07USD

Have questions? We're here to help!

Call

Configure

Used in

DVP 120 Detection Ventilation Control Panels 06838

DVP 120 Detection Ventilation Control Panels 64fc6

DVP 120 Detection Ventilation Control Panels 8b017

The Macurco controller family has various options to meet your facility's needs. In conjunction with Macurco gas detectors, these controllers provide automatic control to help maintain an acceptable environment in parking garages or other applications. These systems easily configure, making installation hassle-free. The control panel series are designed to meet specifications for safety in enclosed parking garages, including the Uniform Building Code and OSHA 50ppm CO requirements. With multiple control panel options Macurco will help you find the suitable controller for your specific application.

• DVP-120: 12 analog (4-20mA) sensor connections

• DVP-120M: 87 digital sensor connections (RS-485) + 12 analog (4-20mA) sensor connections

• Three 10A SPDT fan/alarm relays

• Two 24VDC drivers for horn/strobe

• Compatible with Macurco 6-Series

• Auto recognizes Macurco detectors

• Settings are customizable, default is per OSHA

• DVP-120B: BACnet MSTP output

• DVP-120C: Title 24 compliant (CO & NO2 only)

Size	10.5” x 12.5” x 2.” (10.5 X 37.75 X 5.08 cm)
Weight	6.5 lbs (2.9 kg)
Voltage/Current	Power Input: 90 – 250 VAC, 1 Amp, 47 – 63 Hz, single phase
Operating Temperature	32°F to 120°F (0°C to 49°C)
Ambient Humidity	0% to 90% RH non-condensing
Display	LCD display: 2 rows of 16 characters with backlight
Mounting	Mounting holes in each corner
Relays	Three 10A, 240 VAC SPDT fan/alarm relays
Settings	External keypad for user selection of the transducer/alarm display and setting the configuration
Status Indicators	(LED): Power, ALARM/warning, hush, Relay 1, Relay 2 & Relay 3
Alarms	Drivers for external Horn and Strobe, externally visible system, alarm and relay status indicators
Enclosure	Lockable NEMA 1 type enclosure
Certifications	ETL Listed to UL 2017 CAN/CSA-C22.2 No. 14-13, LADBS Approved
Warranty	Two Year Limited Warranty

• Parking Garages
• Car Dealerships
• Ambulance/Fire House Bays
• Warehouses
• Manufacturing
• Loading Docks
• Mechanical Rooms
• Distribution Centers
• Vehicle Repair Facilities
• Bus Depots
