Datum 2000™ Meter and Manometer
Self-contained dual channel system for accurately displaying an output from one or two transducers (or transmitters) located at a remote location
Dual Channel Meter
The DATUM 2000™ is a self-contained dual channel system for accurately displaying an output from one or two transducers (or transmitters) located at a remote location. It features an analog to digital converter with an LED display. Programmed with a selectable menu, the DATUM 2000™ can be calibrated by the user to the pressure ranges of the various Setra pressure transducers and transmitters or other analog instruments. Two buttons conveniently located on the front panel allow the user to access the menu. The menu includes: selecting a channel, adjusting or calibrating the output of the meter, setting the decimal point, zero adjustment and Hi/Lo Alarms.
Manometer w/Transducer Installed
The DATUM 2000™ Manometer is a complete system with built-in pressure or vacuum transducer. A wide selection of standard pressure ranges is available for gauge, absolute, differential and vacuum measurements from ±0.25 inches WC to 1000 psi. The transducer installed in the Manometer operates on channel one of the two channel meter. Channel two is available for any other voltage or current input from another remote instrument. Setra pressure transducer Models 204, 204D, 239and 270 are available for installation in the 1/4 DIN Datum Manometer.
• Dual Channel
• User Adjustable Hi/Lo Alarms
• Easy Front Panel Setup
• Pressure Displayed in Desired Engineering Units
• Tabletop or Panel Mount
• Use with Voltage or Current Output Devices
• Internal Ground Referenced 12 VDC and 24 VDC Power Supply Provides Excitation Power for the Setra Pressure Transducer
• UL Approved Power Supply
• 1/8 DIN Package (Meter)
• 1/4 DIN Package (Manometer)
• High Accuracy
• Internal Reference Voltage for Easy Calibration
• Dual channel
• User adjust Hi/Lo alarms
• Easy front panel setup
• Pressure displayed in desired engineering units
• Tabletop or panel mount
