CDTC Communicating Carbon Dioxide Sensor

Name: CDTC Communicating Carbon Dioxide Sensor
SKU: placeholder-cdtc-communicating-carbon-dioxide-sensor
Price: 360.00 USD
Availability: InStock

Combines the function of two room sensors into a single, compact housing

Starting at

$360.00USD

Have questions? We're here to help!

Call

Configure

Used in

CDTC Communicating Carbon Dioxide Sensor 08688

CDTC Communicating Carbon Dioxide Sensor 2e9cf

CDTC Communicating Carbon Dioxide Sensor 87b4f

CDTC Communicating Carbon Dioxide Sensor ce801

The Series CDTC Communicating Carbon Dioxide Sensor combines the function of two room sensors into a single, compact housing. Parameters include carbon dioxide, temperature, and temperature set point with override. A 4-wire connection and daisy chaining together reduces installation cost. The RS-485 MAC address is set up using on-board DIP switches. Additional DIP switches are used to select Modbus® RTU or BACnet MS/TP and to limit access to the set up menu. The barometric pressure can be programmed to correct for altitude. Optional integral display is available to display temperature, or temperature set point instead of CO2.

*For environments occupied 24 hours per day it is recommended to periodically expose the CO2 sensor to outside ambient air.

• Minimize inventory and save time by combining CO2 and temperature measurements into one transmitter

• Reduces the number of devices mounted in the space with integral temperature sensing

• Requires minimal maintenance with Automatic Baseline Correction (ABC) to account for sensor drift

• Field selectable Modbus® and BACnet communications reduces wiring

• Simplify installation with backplate electrical connection

Compliance	BTL, CE.
Weight	4.4 oz (125 g).
Power Requirements	10-42 VDC or 10-30 VAC.
Humidity Limits	10 to 95% RH (non-condensing).
Output	2-wire RS-485, Modbus® RTU or BACnet MS/TP communication protocol.
Temperature Limits	32 to 122°F (0 to 50°C).
Sensor Technology	NDIR (non-dispersive infrared); 15 year light source.
Response Time	<2 minutes, diffusion, carbon dioxide.
Range	0 to 2000 or 5000 PPM CO2 (depending on model); 32 to 122°F (0 to 50°C) temperature.
Accuracy	±40 PPM ±3% of reading carbon dioxide; Temperature: ± 1°C @ 25°C.
