88V / 88V/A 88 Series V Deluxe Automotive Multimeter

Name: 88V / 88V/A 88 Series V Deluxe Automotive Multimeter
SKU: placeholder-88v-88v-a-88-series-v-deluxe-automotive-multimeter
Price: 596.39 USD
Availability: InStock

Improved measurement functions, trouble-shooting features & accuracy to solve more problems on conventional & hybrid vehicles

Have questions? We're here to help!

Call

Used in

88 V 88 VA 88 Series V Deluxe Automotive Multimeter 01080

The Fluke 88V meter has measurement functions, troubleshooting features, and accuracy levels needed to solve problems on conventional and hybrid vehicles. The 88V is the most powerful automotive multimeter ever offered by Fluke. In addition to standard multimeter features such as the ability to measure voltage, current, continuity, and resistance, the 88V can perform:

Pulse width

Duty cycle

Min/Max/Average recording

Diode tests

The pulse width function provides millisecond resolution for troubleshooting fuel injectors.

Automotive measurements

The 88V meter can take care of many automotive needs, getting into more of the digital multimeters measurement capabilities - it can measure voltage up to 1000 V AC and DC, current up to 10 A, 20 A for up to 30 seconds and frequency to 200 kHz and % duty cycle. Add those features to RPM measurements with optional inductive pickup and millisecond pulse width measurements for fuel injectors to name a few. The 88V comes packed with the functions you need:

Temperature measurements with optional temperature probe

Analog bar graph to track changing or unstable signals

Min/Max/Average recording with Min/Max Alert to capture variations automatically

Peak Min/Max to record transients as fast as 250 μs

88V multimeter designed for the garage

While working in a garage, the large display digits can help you focus on the vehicle while still being able to read the numbers. Plus, the two-level bright white backlight offers the additional visibility you may need.

An optional magnetic hanger lets you hang the meter from most steel surfaces for easy set-up and viewing. The 88V is designed to be used in high energy environments like those found on hybrid vehicles.

The product is supported by a limited lifetime warranty.

• 0.1 % DC accuracy
• Current measurements up to 10 A, 20 A for up to 30 s
• Millisecond pulse width measurements for fuel injectors
• Built in thermometer lets you carry one less tool (temperature probe included)
• Min/Max/Avg recording with Min/Max Alert to capture variations automatically
• Peak Min/Max to record transients as fast as 250 μs
• Relative mode to remove test lead resistance from low Ω measurements
• Auto and manual ranging for maximum flexibility
• Autohold™ to capture stable readings with only one touch of the leads
• Large display digits and two-level bright white backlight for increased visibility
• Analog bargraph to track changing or unstable signals
• Input Alert provides audible warning against wrong use of input jacks
• Access door for fast battery changes without opening up the case
• “Classic” design that fits your hand and features a new removable holster, built-in test lead, and probe storage
• 10 MΩ input impedance won’t load or damage computer circuits
• Optional magnetic hanger allows meter to attach to the vehicle and free your hands for other tasks
• Limited lifetime warranty

Technical Specifications
DC Voltage	Maximum Voltage	1000 V
	Accuracy	+/- (0.1% + 1)
	Best Resolution	0.01 mV
AC Voltage	Maximum Voltage	1000 V
	Accuracy	+/- (0.5% + 2)
	AC Bandwidth	5 kHz
	Best Resolution	0.01 mV
DC Current	Maximum Amps	10 A
	Amps Accuracy	+/- (0.4% + 2)
	Best Resolution	0.001 mA
AC Current	Maximum Amps	10 A
