325 True-RMS Clamp Meter

Name: 325 True-RMS Clamp Meter
SKU: placeholder-325-true-rms-clamp-meter
Price: 679.46 USD
Availability: InStock

Small & rugged clamp meters are ideally suited for current measurements up to 400 A in tight cable compartments

Have questions? We're here to help!

Call

Used in

Troubleshoot problems safely and accurately

The Fluke 325 True-rms Clamp Meter is a reliable, versatile troubleshooting tool for commercial and residential electricians. Featuring a slim design for easy transport and use, and a large display for efficient troubleshooting. In addition to true-rms AC current and voltage on non-linear loads, the 325 measures:

• DC current

• DC voltage

• Temperature

• Frequency

You’ll carry fewer tools in your bag and get more work done.

Covers most problems you see day-in, day-out

The 325 gives you a strong combination of measurement functions, in a tool that is reliable, easy-to-use and affordable. This clamp meter offers True-rms AC voltage and current measurements on non-linear signals. Paired with the CAT III 600 V, CAT IV 300 V safety rating the clamp meter can also measure:

Measures AC/DC current up to 400 A through jaw

AC/DC voltage to 600 V using test leads

Measures frequency from 5 Hz to 500 Hz; resistance to 40 kΩ

Measures temperature from -10 °C to 400 °C with included K-type thermocouple

Min/Max function records important values

Comes with a two-year warranty

• True-rms AC/DC current, voltage, temperature, frequency

• Clamp meter, test leads, K-type thermocouple and soft case

• Versatile tool performs most front-line measurement tasks

AC current	Range 40.00 A / 400.0 A Accuracy 2% ± 5 digits (45 Hz to 65 Hz) 2.5% ± 5 digits (65 Hz to 400 Hz)
DC current	Range 40.00 A / 400.0 A Accuracy 2% ± 5 digits
AC voltage	Range 600.0 V Accuracy 1.5% ± 5 digits
DC voltage	Range 600.0 V Accuracy 1.0% ± 5 digits
Resistance	Range 400.0 Ω / 4000 Ω / 40.00 kΩ Accuracy 1.0% ± 5 digits
Continuity	0 to 100.0 μF / 100μF to 1000 μF
Frequency	True-RMS
Backlight	Yes
Data hold	Yes
Contact temperature	-10.0°C to 400.0°C (14.0°F to 752.0°F)
Min/Max	Yes
Size	H x W x D (mm) 207 x 75 x 34 Max wire diameter 30 mm (600 MCM) Weight 283 g
Category rating	CAT III 600 V CAT IV 300 V
Warranty	Two-year
