Fluke

3000FC Series Wireless Multimeter

Independently tested for safe use in CAT IV 600V/ CAT III 1000 V environments

Have questions? We're here to help!
Have questions? We're here to help!

With its precision, reliability and ease of use, the Fluke 3000FC Wireless Multimeter is the ideal solution for professional technicians. Independently tested for safe use in CAT IV 600V/ CAT III 1000 V environments, the Fluke 3000FC has all the features you need to troubleshoot and repair many problems in electrical and electronic systems. The Fluke 3000FC gives you True-RMS voltage and current measurements, 6000 count resolution, manual and automatic ranging and provide frequency, capacitance, resistance, continuity and diode measurements. In addition, the Fluke 3000FC provides higher 0.09% basic accuracy, a digital display showing up to three secondary measurements from remote modules, and a bright white backlight.

The Fluke 3000FC True-RMS Wireless Multimeter and Fluke Connect wireless test tools put tools, not your body, near live electrical panels. Better still, the Fluke 3000FC Series Wireless Multimeter can send measurement data to your smartphone, so you can save and share measurements from the field with your team anytime, from anywhere.

3000FC/EDA2 Multimeter and Deluxe Accessories Combo Kit Includes:
• 3000FC True-RMS Series Wireless Multimeter
• TL910 electronic test probes
• TL224 silicone test leads
• AC280 heavy duty hook clips
• C35 lightweight soft carrying case
• ToolPak™ magnetic meter hanger
• Installed batteries
• User's manual CD

3000FC/1AC2 Multimeter and Non-Contact Voltage Detector Combo Kit Includes:
• 3000FC True-RMS Series Wireless Multimeter
• 1ACII non-contact voltage tester
• TL224 silicone test leads
• TP175 industrial test probes
• AC220 heavy duty alligator clips
• C35 lightweight soft carrying case

3000FC/TPAK Meter and Magnetic Hanger Combo Kit Includes:
• 3000FC True-RMS Series Wireless Multimeter
• TL75 test leads
• C35 lightweight soft carrying case
• ToolPak™ magnetic meter hanger
• Installed batteries
• User's manual CD

• Full featured multimeter that also reads results wirelessly from remote Fluke Connect® wireless modules
• Measures AC and DC voltage to 1000 V, AC and DC current, and temperature
• Shows up to four readings simultaneously on a bright white backlit display
• Sends measurement data to your smartphone
• Safety rated CAT III 1000 V, Cat IV 600 V; IP54
Range¹ / resolution 600.0 mV / 0.1 mV
6.000 V / 0.001 V
60.00 V / 0.01 V
600.0 V / 0.1 V
1000 V / 1 V

Accuracy2 3 4 45 Hz to 500 Hz 1.0% + 3
500 Hz to 1 kHz 2.0% + 3
1. AC voltage ranges are specified from 1% of range to 100% of range.
2. Crest factor of ≤ 3 at full scale up to 500 V, decreasing linearly to crest factor < 1.5 at 1000 V.
3. For non-sinusoidial waveforms, add ± (2% of reading + 2% full scale) typical, for crest factor up to 3.
4. Do not exceed 107 V-Hz.
mV Range / resolution 600.0 mV / 0.1 mV
Accuracy 0.09% + 2
V Range / resolution 6.000 V / 0.001 V
60.00 V / 0.01 V
600.0 V / 0.1 V
1000 V / 1 V
V Accuracy
))) Range / resolution 600 Ω / 1 Ω
))) Accuracy Meter beeps at < 25 Ω, beeper detects opens or shorts of 250 μs or longer.
Ω Range / resolution 600.0 Ω / 0.1 Ω
6.000 kΩ / 0.001 kΩ
60.00 kΩ / 0.01 kΩ
60.00 kΩ / 0.1 kΩ
600.0 kΩ / 0.001 MΩ
50.00 MΩ / 0.01 MΩ
Ω Accuracy 0.5% + 2
0.5% + 1
1.5% + 3
Diode test Range / resolution 2.000 V / 0.001 V
Diode test Accuracy 1% + 2
µF Range / resolution 1000 nF / 1 nF
10.00 μF / 0.01 μF
100.0 μF / 0.1 μF
9999 μF1 / 1 μF
µF Accuracy 1.2% + 2
10% typical
AC and DC Current
mA AC (45 Hz to 1 kHz) Range1 / resolution 60.00 mA / 0.01 mA
400.0 mA3 / 0.1 mA
mA AC (45 Hz to 1 kHz) Accuracy 1.5% + 3
mA DC2 Range1 / resolution 60.00 mA / 0.01 mA
400.0 mA3 / 0.1 mA
mA DC2 Accuracy 0.5% + 3
1. All AC current ranges are specified from 5% of range to 100% of range.
2. Input burden voltage (typical): 400 mA input 2 mV/mA.
3. 400.0 mA accuracy specified up to 600 mA overload.
Frequency
Range / resolution 99.99 Hz / 0.01 Hz
999.9 Hz / 0.1 Hz
9.999 kHz / 0.001 kHz
99.99 kHz / 0.01 kHz
Accuracy1 0.1% + 1
1. Frequency is specified up to 99.99 kHz in volts and up to 10 kHz in amps.
mA Function
Overload protection Fused, 44/100 A, 1000 V FAST Fuse
Overload 600 mA overload for 2 minutes maximum, 10 minutes rest minimum
MIN/MAX Recording Accuracy
DC functions ± 12 counts for changes > 350 mS in duration.
AC functions ± 40 counts for changes > 900 mS in duration.
Maximum voltage between any terminal and earth ground 1000 V DC or AC RMS
Ω fuse protection from A inputs 0.44 A (44/100 A, 440 mA), 1000 V FAST Fuse, Fluke specified part only
Display (LCD) Update rate 4/sec
Display (LCD) Volts, amps, ohms 6000 counts
Display (LCD) Frequency 10,000 counts
Capacitance 1,000 counts
Battery type Three AA Alkaline batteries, NEDA 15A IEC LR6
Battery life 250 hours minimum
RF communications 2.4 GHZ ISM Band
RF communication range Open air, unobstructed Up to 20m
Obstructed, sheetrock wall Up to 6.5m
Obstructed, concrete wall, or steel electrical enclosure Up to 3.5m
Temperature Operating -10°C to 50°C
Storage -40°C to 60°C
Temperature coefficient 0.1 X (specified accuracy) / °C (< 18°C or > 28°C)
Relative humidity 0% to 90% (0°C to 35°C)
0% to 75% (35°C to 40°C)
0% to 45% (40°C to 50°C)
Altitude Operating 2,000 m
Storage 12,000 m
Electromagnetic compatibility EMI, RFI, EMC, RF EN 61326–1:2006, EN 61326–2–2:2006
ETSI EN 300 328 V1.7.1:2006, ETSI EN 300 489
V1.8.1:2008
FCC Part 15 Subpart C Sections 15.207, 15.209, 15.249
FCCID : FCC: T68–FDMMBLE IC: 6627A–FDMMBLE
Safety compliance ANSI / ISA 61010–1 / (82.02.01): 3rd edition
CAN / CSA-C22.2 No 61010-1-12: 3rd edition
UL 61010–1: 3rd edition
IEC / EN 61010–1:2010
Certifications CSA, FCC, CE
Ingress Protection (IP) rating IP54
Pollution Degree 2
Size (H x W x L) 4.75 x 9.3 x 20.7 cm (1.87 x 3.68 x 8.14 in)
Weight 340 g (12 oz)
Warranty Three years
