209 Gauge Pressure Transducer

The Model 209 pressure sensor is designed for Industrial and OEM customers who require high performance, reliability and versatility at an affordable price.  It offers exceptional ±0.25% FS accuracy with pressure ranges from 1 PSI up to 10,000 PSI to meet a multitude of demanding applications.  The 209 features all stainless steel wetted materials and offers many pressure and electrical connections to satisfy challenging installation requirements.  The 209 features a patented overpressure stop to protect the sensor against unexpected spikes or in high pulsation applications.

True Low Range Sensor - The Model 209 is a capacitive transducer that is designed for industrial applications with demanding price and performance requirements.  The Model 209 offers exceptional reliability in typical industrial grade environments.  The true low range sensor design offers high performance with no additional amplification required to meet range requirements down to 1 PSI.

Flexibility for Many Applications - The 209 transducer offers many pressure and electrical fittings covering many installation configurations.  It minimizes additional engineering time to accommodate the sensor, allowing for earlier project completion and quicker time to market.

Robust Design & Construction for Reliable Service - The Model 209 is designed and build to withstand demanding applications.  The industrial construction, with optional positive overpressure stop, enables the sensor to withstand overpressure conditions up to 16X the rated range.
